SF188R0 Thermal Fuse 15A 192°C 250V AC – SCHOTT SF/R Series

Thermal fuses are indispensable components in modern electronic and electrical systems, serving as critical safety devices that prevent overheating and protect circuits from fire or catastrophic failure. One such reliable component is the SF188R0 Thermal Fuse, part of the renowned SCHOTT SF/R Series. With a rated capacity of 15A, an operating temperature of 192°C, and a 250V AC voltage tolerance, the SF188R0 fuse is widely used in consumer electronics, home appliances, industrial equipment, and more.

This article will explore the features, working principles, applications, advantages, and usage guidelines for the SF188R0 thermal fuse, providing a complete understanding of why it's a go-to choice for thermal protection in electronic systems.

What Is a Thermal Fuse?

A thermal fuse (also known as a thermal cutoff or thermal link) is a safety component that interrupts electrical current when a pre-set temperature is exceeded. Unlike resettable thermal switches or thermostats, thermal fuses are non-resettable, meaning they permanently break the circuit once triggered. This ensures a higher level of safety, especially in environments where overheating poses significant risks.

Introduction to SCHOTT and the SF/R Series

SCHOTT Electronic Packaging is a globally recognized manufacturer of safety and protective electronic components, especially known for their SF/R series of thermal fuses. These fuses are engineered for high reliability, precision, and compliance with international safety standards.

The SF/R Series fuses, including the SF188R0, are widely appreciated for their:

• Compact and sealed construction

• Stable and accurate opening temperatures

• Fast response time

• High interrupt capacity

• Environmental and thermal durability

Key Specifications of SF188R0

How Does the SF188R0 Work?

The SF188R0 thermal fuse operates through a fusible alloy sealed within its body. Under normal operating temperatures, the alloy remains solid, allowing current to pass through uninterrupted. When the ambient or component temperature reaches 192°C, the alloy melts and breaks the circuit.

This simple, yet effective, mechanism ensures:

• Instant disconnection when overheating is detected

• Irreversible action to avoid resetting under unsafe conditions

• Isolation of heat sources before they can cause damage

The SF188R0 is a fail-safe mechanism — it is activated only in abnormal conditions, ensuring long-term reliability in day-to-day operations.

Applications of SF188R0 Thermal Fuse

Due to its high amperage and temperature rating, the SF188R0 is suitable for various applications that demand dependable thermal protection.

1. Home Appliances

• Hairdryers

• Coffee machines

• Electric kettles

• Irons

• Microwave ovens

• Toasters



Appliances with heating elements rely on thermal fuses like the SF188R0 to shut down in case of thermostat failure or blocked vents.

2. Consumer Electronics

• Battery chargers

• Power supplies

• Electric fans

• Heaters

By integrating thermal fuses, these devices prevent overheating caused by short circuits or prolonged use.

3. Industrial Equipment

• Motor drives

• Transformers

• Circuit protection systems



In industrial settings, the SF188R0 offers protection where precision temperature control is critical, ensuring both safety and compliance.

4. Medical Devices and Lab Instruments

• Heating pads

• Thermal cyclers



• Incubators

The precision cutoff temperature helps protect sensitive devices and samples from overheating or failure.

Advantages of Using SF188R0

High Accuracy

The fuse activates precisely at 192°C, ensuring no false trips or premature failure, even in varying thermal environments.

Fast Response Time

It reacts quickly once the threshold is crossed, which minimizes damage to surrounding components and reduces the risk of fire.

Compact Design

Its small footprint makes it ideal for tightly packed devices, without compromising performance.

High Reliability

SCHOTT’s rigorous quality control ensures each fuse delivers consistent performance, even after prolonged exposure to high temperatures.

1. Avoid Mechanical Stress

Bending the leads too close to the body or applying force during soldering can damage the internal fusible link. Always bend leads at least 3mm from the body.

2. Heat Isolation During Soldering

Avoid applying excessive heat directly to the fuse during installation. Use heat sinks or quick soldering methods to prevent premature opening.

Alternatives and Cross-References

While the SF188R0 is a high-performing component, there are other thermal fuses available with similar ratings. Some alternatives include:

• Thermodisc G4 Series (192°C/15A)

When selecting an alternative, ensure it matches the voltage, current, and temperature ratings exactly to avoid under- or over-protection.

Where to Buy SF188R0

The SF188R0 thermal fuse is available through a wide range of online distributors, including:

• Nikko Electronics (nikkoe.com)

• Mouser Electronics

When purchasing, confirm that the product is genuine and meets certification standards. Reputable distributors often list datasheets and certifications for buyer confidence.

Conclusion

The SF188R0 Thermal Fuse from the SCHOTT SF/R Series is a reliable and accurate thermal protection device suitable for a wide range of applications. With a current rating of 15A, a cutoff temperature of 192°C, and a robust 250V AC tolerance, it is engineered for dependable operation in both consumer and industrial environments.
